Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

133
Remote I/O Terminals with Transistors Section 5-5
Components of the DRT2-ID16TA and DRT2-ID16TA-1
Internal Circuits
DRT2-ID16TA (NPN)
DRT2-ID16TA-1 (PNP)
Rotary switches (×10, ×1)
Set the node address.
DeviceNet Indicators
Input indicators
Indicate the input status of each contact.
(Lit when the input is ON.)
Communications
connector
DIN track mounting hooks
Terminal block
Circuit removal screws.
DRT2-ID16TA
REMOTE TERMINAL DC24V
NS
MS
Spare
terminals
V+
CAN_H
DRAIN
CAN_L
V−
V1 24 V D
C
G1
V1
0 to 7
G1
Photocoupler
V2 24 V D
C
G2
V2
8 to 15
G2
Photocoupler
Physical
layer
Internal
circuitry
DC-DC
converter
(non-
isolated)
V+
CAN_H
DRAIN
CAN_L
V−
V1 24 V DC
G1
V1
0 to 7
G1
Photocoupler
V2 24 V DC
G2
V2
8 to 15
G2
Photocoupler
Physical
layer
Internal
circuitry
DC-DC
converter
(non-
isolated)
