172
Connector Terminals with Transistors Section 5-6
Internal Circuits
DRT2-MD32ML (NPN)
DRT2-MD32ML-1 (PNP)
V1
G1
V2
G2
V+
CAN_H
DRAIN
CAN_L
V−
Internal
circuitry
Photo-
coupler
Input
Photo-
coupler
Output
Voltage
step-down
Physical
layer
DC-DC
converter
(non-
isolated)
V2
G2
G1
V1
V+
CAN_H
DRAIN
CAN_L
V−
Internal
circuitry
Input
Output
Voltage
step-down
Physical
layer
DC-DC
converter
(non-
isolated)
Photocoupler
Photocoupler
