Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

197
Connector Terminals with Transistors Section 5-6
I/O Allocations The input word and output word allocated to the Remote I/O Terminal are
referred to as “word m” and “word n” respectively. Given this, the bit and word
allocations to MIL connector pin numbers are as shown in the following dia-
gram.
Dimensions
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
25 27 29 31 33 35 37 39 26 28 30 32 34 36 38 40
5
Wd m
Wd n 7 9 1113151719 6 8 101214161820
Bit
16 inputs
16 outputs
DRT2-MD32BV (NPN)/DRT2-MD32BV-1 (PNP)DRT2-MD32B (NPN)/DRT2-MD32B-1 (PNP)
