294
Overview of Analog Slaves Section 7-1
Temperature Input Terminals
Input range switching Set using the rotary switches. Set using the DIP switch or the Configura-
tor.
Node address setting Set using the DIP switch. Set using the rotary switches or the Config-
urator.
Baud rate setting Set using the DIP switch. Automatically detected: Uses the baud rate
set for the Master Unit.
Communications error output Set using the DIP switch. Set using the Configurator.
Scaling, user adjustment
(maintenance function), cumu-
lative counter (maintenance
function), last maintenance
date (maintenance function)
Not supported. Supported. (Set using the Configurator.)
Slave DRT1 Series DRT2 Series
Model DRT1-TS04T DRT1-TS04P DRT2-TS04T DRT2-TS04P
Input type Thermocouple Platinum resistance
thermometer
Thermocouple Platinum resistance
thermometer
Dimensions 150 × 40 × 50 (W × H × D) 115 × 49.7 × 50 (W × H × D)
Maintenance method Replacement of each Unit Just the Terminal Block can be removed.
Input type setting method Set with a Rotary Switch. Set with a DIP switch (hardware) setting or
Configurator (software) setting.
Input type setting All 4 inputs are set together. Inputs can be set individually.
(All inputs are set to the same input type if
the DIP switch (hardware) setting is used. In
addition, the following settings cannot be
set individually: Off-wire (disconnection)
display setting, Number of display digits set-
ting, and °C/°F setting.)
Input type (sensor type) R, S, K1, K2, J1, J2,
T, B, L1, L2, E, U, N,
W, PL2
PT, JPT R, S, K1, K2, J1, J2,
T, B, L1, L2, E, U, N,
W, PL2
PT, JPT, PT2, JPT2
Input accuracy
±0.5% of indication
value or
±2°C,
whichever is larger)
±1 digit max.
±0.5% of indication
value or
±1°C,
whichever is larger)
±1 digit max.
±0.3% of indication
value or
±1°C,
whichever is larger)
±1 digit max.
(See note.)
−200 to 850°C input
range:
±0.3% of indication
value or
±0.8°C,
whichever is larger)
±1 digit max.
−200 to 200°C input
range:
±0.3% of indication
value or
±0.5°C,
whichever is larger)
±1 digit max.
Conversion cycle 250 ms/ 4 points
1/100 display mode The temperature data is multiplied by 100
and sent to the Master as 6-digit hexadeci-
mal data. In this case, the hexadecimal data
is divided into two parts and the parts are
sent alternately each 125 ms. (The data is
sent in 1-word units).
The temperature data is multiplied by 100
and sent to the Master as 8-digit hexadeci-
mal data. (The data is sent in 2-word units).
DRT1-compatible 1/100 dis-
play mode
--- The temperature data is multiplied by 100
and sent to the Master as 6-digit hexadeci-
mal data. In this case, the hexadecimal data
is divided into two parts and the parts are
sent alternately each 125 ms. (The data is
sent in 1-word units).
Slave DRT1 Series DRT2 Series
Model DRT1-DA02 DRT2-DA02
