Analog Output Terminals Section 7-5
Output Range: 1 to 5 V The values 0000 to 1770 hex (0 to 6,000) correspond to the voltage range 1 to
5 V. The output range is 0.8 to 5.2 V.
Output Range: 0 to 10 V The values 0000 to 1770 hex (0 to 6,000) correspond to the voltage range 0 to
10 V. The output range is
–0.5 to 10.5 V.
Output Range:
–10 to 10 V The values F448 to 0BB8 hex (–3,000 to 3,000) correspond to the voltage
range
–10 to 10 V. The output range is –11 to 11 V. Negative voltages are
specified as two’s complements (16 bits).
Output Range: 4 to 20 mA The values 0000 to 1770 hex (0 to 6,000) correspond to the current range 4 to
20 mA. The output range is 3.2 to 20.8 mA.
FED4
(−300)
189C
(6300)
1770
(6000)
0000(0)
1 V
0 V
0.8 V
5.2 V
5 V
8000
7FFF
Conversion data
Hexadecimal (decimal)
Voltage
FED4 (−300)
189C
(6300)
1770
(6000)
0000 (0)
0 V
−0.5 V
10.5 V
10 V
8000
7FFF
Conversion data
Hexadecimal (decimal)
Voltage
F31C
(−3300)
F448
(−3000)
0CE4
(3300)
0BB8
(3000)
0000 (0)
0 V
11 V
10 V
−10 V
−11 V
8000
7FFF
Conversion data
Hexadecimal (decimal)
Voltage
FED4
(−300)
189C
(6300)
1770
(6000)
0000(0)
4 mA
0 mA
3.2 mA
20.8 mA
20 mA
8000
7FFF
Conversion data
Hexadecimal (decimal)
Current
