DRT2 Slaves Section 1-2
Note Use the following table to determine the I/O power supply for the Expansion
Unit.
General-pur-
pose Slaves
Standard
rectangular
connector
MIL Connec-
tor Terminals
with Transis-
tors
DRT2-ID32ML DIN Track
or screws
with Mount-
ing Bracket
MIL con-
nector
Shares
communi-
cations
power sup-
ply.
Requires
external
power sup-
ply.
DRT2-ID32ML-1
DRT2-OD32ML
DRT2-OD32ML-1
DRT2-MD32ML
DRT2-MD32ML-1
Board MIL
Connector
Te r m in al s
with Transis-
tors
DRT2-ID32B Screws
DRT2-ID32B-1
DRT2-OD32B
DRT2-OD32B-1
DRT2-MD32B
DRT2-MD32B-1
DRT2-ID32BV
DRT2-ID32BV-1
DRT2-OD32BV
DRT2-OD32BV-1
DRT2-MD32BV
DRT2-MD32BV-1
Screw-less
Clamp Termi-
nal with Tran-
sistors
DRT2-ID16SL DIN Track Screw-less
clamp
DRT2-ID16SL-1
DRT2-OD16SL
DRT2-OD16SL-1
DRT2-ID32SL
DRT2-ID32SL-1
DRT2-OD32SL
DRT2-OD32SL-1
DRT2-MD32SL
DRT2MD32SL-1
DRT2-ID16SLH
DRT2-ID16SLH-1
DRT2-OD16SLH
DRT2-OD16SLH-1
DRT2-ID32SLH
DRT2-ID32SLH-1
DRT2-OD32SLH
DRT2-OD32SLH-1
DRT2-MD32SLH
DRT2-MD32SLH-1
Device combination I/O power supply to Expansion Unit
Basic Input Unit (IN) + Expansion Input
Unit (IN):
Example: DRT2-ID16+XWT-ID16
Not required. (I/O power supply shared
with Basic Unit.)
Basic Input Unit (IN) + Expansion Output
Unit (OUT):
Example: DRT2-ID16+XWT-OD16
Required. (I/O power supply required for
both Units.)
Slave type Communi-
cations
cables
Name Model Slave
installation
I/O con-
nection
method
Internal
power sup-
ply
I/O power
supply
