558
Connectable Devices Appendix D
Crimp Terminals for Communications Cables
PHOENIX CONTACT: A/AI Series
Screwdrivers for Connectors
Terminating Resistors
Note A Terminating Resistor can also be connected to a T-branch Tap.
T- b r a n c h Ta p s
T-branch Connectors
Power Supply Sharing Taps
Cable type Connector type Dedicated tool
XW4B-05C1-H1-D
XW4B-05C1-V1R-D
MSTB2.5/5-ST-5.08AU
XW4B-05C4-TF-D
XS4B-05C4-T-D
XW4G-05C1-H1-D
XW4G-05C4-TF-D
For Thin
Cable
Signal line AI 0.25-6BU AI 0.25-8YE AI 0.25-8YE CRIMPFOX
ZA3
Power line AI 0.5-6WH AI 0.5-10WH AI 0.5-10WH
For Thick
Cable
Signal line A1-6 A1-10 A1-10
Power line AI 2.5-8BU AI 2.5-10BU AI 2.5-10BU
Model Specifications Manufacturer (Supplier)
XW4Z-00C Special screwdriver for DeviceNet connectors OMRON
SZF-1 Special screwdriver for DeviceNet connectors OMRON 24 Service Co., Ltd.
Model Specifications Manufacturer
DRS1-T Terminal-block Terminating Resistor, 121 Ω OMRON
DRS2-1 Shielded Terminating Resistor (male plug), micro-size
DRS2-2 Shielded Terminating Resistor (female socket), micro-size
DRS3-1 Shielded Terminating Resistor (male plug), mini-size
Model Specifications Manufacturer
DCN1-1C Includes 3 connectors (When used on a trunk line, 1 branch line can be con-
nected.)
A Terminating Resistor can be connected.
OMRON
DCN1-3C Includes 5 connectors (When used on a trunk line, 3 branch lines can be
connected.)
A Terminating Resistor can be connected.
OMRON
Model Specifications Manufacturer
DCN2-1 Shielded T-branch Connector (for 1 branch line) OMRON
Model Specifications Manufacturer
1485T-P2T5-T5 Required when connecting more than one power supply.
Reverse current prevention, ground terminal provided.
Allen-Bradley
DCN1-1P One-branch tap for power supply.
Use this tap when connecting a communications power supply.
Two connectors and two fuses are standard.
OMRON
To Next Page
