Chapter 6: Connectivity
I/O 2
Connector type TE Micro-mate N Lok., 2 x 12
Pin
No.
Designation Notes
1 DIGITAL_OUTPUT_1 0.5A @ 24VDC
2 DIGITAL_OUTPUT_2 0.5A @ 24VDC
3 DIGITAL_OUTPUT_3 0.5A @ 24VDC
4 DIGITAL_OUTPUT_4 0.5A @ 24VDC
5 GND
6 GND
7 ANALOG_OUTPUT_1 0.1A
8 ANALOG_OUTPUT_2 0.1A
9 GND
10 GND
11 DIGITAL_OUTPUT_5 0.5A @ 24VDC
12 GND
13 DIGITAL_OUTPUT_6 0.5A @ 24VDC
14 DIGITAL_OUTPUT_7 0.5A @ 24VDC
15 DIGITAL_OUTPUT_8 0.5A @ 24VDC
16 GND
17 GND
18 ANALOG_OUTPUT_3 0.1A
19 ANALOG_OUTPUT_4 0.1A
20 GND
21 GND
22 GND
23 GND
24 GND
COMMS - RS-232, RS-422, CANBus
Connector type TE Micro-mate N Lok., 2 x 7
