111 HD-1500 Platform User's Manual 31500-000 Rev A
3.7 Installing the Charging Station
interferes with power supply box's cooling process. Refer to Power supply box cooling
duct on page 227 for location of the air vents.
Required Tools and Fasteners
The tools and fasteners required for the installation of the charging station are described in
Table 3-5. below.
IMPORTANT: If you do not use appropriate fasteners for sustained use, the
docking target will move during the docking attempts, causing docking and char-
ging failures. The docking target mounting holes are 9 mm in diameter.
Table 3-5. Required Tools and Fasteners
Size Qty Description
As
required
As
required
Appropriate screwdriver, hex socket, or driver bit for the fasteners that
you supply. (user-supplied)
M12 6 M12 bolts - used to anchor the power supply box to the floor. (user-sup-
plied)
M12 6 M12 Fender washer - used with M12 bolts. (user-supplied)
M10 4 M10 bolts - used to mount the power supply box to the wall. (user-sup-
plied)
M10 4 M10 washer - used with the M10 bolts. (user-supplied)
M8 8 M8 bolts - used to mount the docking target to the floor/wall. (user-sup-
plied)
N/A 8 Docking target mounting brackets. (OMRON-supplied, part number
68910-105)
N/A 1 Cable clampFigure 3-67.
