Chapter 3: Setup
Figure 3-2. HD-1500 Moving Down the Ramp
The following figures display dimensions of the HD-1500 crate. All dimensions are in mm.
1969
1448
991
Figure 3-3. HD-1500 Shipping Crate Outer Dimensions
31500-000 Rev A HD-1500 Platform User's Manual 66
