4
-
14
nDigital
Operator
Displays
during
Autotuning
The
following
displays
will
appear
on
the
Digital
Operator
during
autotuning.
Table 4.5 Digital Operator Displays during Autotuning
Digital Operator Display Description
Autotuning
mode
selection:
T1-01
Using
the
same
procedures
as
for
the
programming
modes
check
and
set
the
T1
parameters
according
to
information
on
the
previous
page.
Be
sure
that
T1-01
(Autotuning
Mode
Selection)
is
set
correctly
and
check
safety
around
the
motor
and
machine.
Motor
base
speed:
T1-07
(For
rotational
autotuning)
The
autotuning
start
display
will
appear
when
all
set-
tings
through
T1-07
have
been
completed.
The
A.TUNE
and
DRIVE
indicators
will
be
lit.
Autotuning
started:
TUn10
Autotuning
will
start
when
the
RUN
Key
is
pressed
from
the
autotuning
start
display.
The
digit
second
from
the
right
in
TUn
oo
is
the
Motor
1/2
Selection
(T1-00)
and
the
right
digit
is
the
Autotuning
Mode
Selection
(T1-01).
Autotuning Stop
command
input
If
the
STOP
Key
is
pressed
or
a
measurement
error
occurs
during
autotuning,
and
error
message
will
be
display
and
autotuning
will
be
stopped.
Refer
to
Errors
during
Autotuning
on
page
7-12.
Autotuning
completed
END
will
be
displayed
after
approximately
1
to
2
min-
utes,
indicating
that
autotuning
has
been
completed.
