Omron SYSDRIVE 3G3RV Series User Manual

D
igital Operator Display Functions and Levels
5
-
7
H4-02
Gain (termi-
nal FM)
Set the voltage level gain for multi-
function analog output 1.
Set the number of multiples of 10 V to
be output as the 100% output for the
monitor items. Voltage output from
the terminals, however, is 10 V max.
A meter calibration function is avail-
able.
0.00 to
2.50
1.00 Yes Q Q Q 41EH
Terminal
FM Gain
H4-05
Gain (termi-
nal AM)
Set the voltage level gain for multi-
function analog output 2.
Set the number of multiples of 10 V to
be output as the 100% output for the
monitor items. Voltage output from
the terminals, however, is 10 V max.
A meter calibration function is avail-
able.
0.00 to
2.50
0.50 Yes Q Q Q 421H
Terminal
AM Gain
L1-01
Motor pro-
tection
selection
Set to enable or disable the motor
overload protection function using the
electronic thermal relay.
0: Disabled
1: General-purpose motor protection
2: Inverter motor protection
3: Vect or motor protection
In some applications when the
Inverter power supply is turned off,
the thermal value is reset, so even if
this parameter is set to 1, protection
may not be effective.
When several motors are connected to
one Inverter, set to 0 and ensure that
each motor is installed with a protec-
tion device.
0 to 3 1 No Q Q Q 480H
MOL Fault
Select
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Regis-
ter
LCD
Display
V/f
V/f
with
PG
Open
Loop
Vec-
tor
