Omron SYSDRIVE 3G3RV Series User Manual

5
-
8
*1.The setting ranges for acceleration/deceleration times depends on the setting of C1-10 (Acceleration/deceleration Time Setting Unit). If C1-10 is set to
0, the setting range is 0.00 to 600.00 (s).
*2.The factory setting depends on the Inverter capacity.
*3.These are values for a 200-V class Inverter. Val ues for a 400-V class Inverter are double.
*4.The upper setting limit will be 150.0 Hz when C6-01 is set to 0.
*5.The factory setting will change when the control method is changed. (V/f control factory settings are given.)
*6.After autotuning, E1-13 will contain the same value as E1-05.
*7.The factory setting depends on the Inverter capacity. (The value for a 200-V class Inverter for 0.4 kW is given.)
*8.The setting range is from 10% to 200% of the Inverter rated output current. (The value for a 200-V class Inverter for 0.4 kW is given.)
*9.The factory setting for (-E) models is 1024.
L3-04
Stall pre-
vention
selection
during
deceleration
0: Disabled (Deceleration as set. If
deceleration time is too short, a
main circuit overvoltage may
result.)
1: Enabled (Deceleration is stopped
when the main circuit voltage
exceeds the overvoltage level.
Deceleration restarts when voltage
is returned.)
2: Intelligent deceleration mode
(Deceleration rate is automatically
adjusted so that in Inverter can
decelerate in the shortest possible
time. Set deceleration time is
disregarded.)
3: Enabled (with Braking Resistor
Unit)
When a braking option (Braking
Resistor, Braking Resistor Unit, Brak-
ing Unit) is used, always set to 0 or 3.
0 to 3 1 No Q Q Q 492H
StallP Decel
Sel
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Regis-
ter
LCD
Display
V/f
V/f
with
PG
Open
Loop
Vec-
tor
