Omron SYSDRIVE 3G3RV Series User Manual

5
-
28
Note The unit is set in o1-03 (frequency units of reference setting and monitor, default: 0.01 Hz).
d1-09
Frequency
reference 9
The frequency reference
when multi-step speed com-
mand 4 is ON for a multi-
function input.
0 to
400.00
0.00
Hz
Yes A A A 288H -
Reference 9
d1-10
Frequency
reference 10
The frequency reference
when multi-step speed com-
mands 1 and 4 are ON for
multi-function inputs.
0.00
Hz
YesAAA28BH -
Reference
10
d1-11
Frequency
reference 11
The frequency reference
when multi-step speed com-
mands 2 and 4 are ON for a
multi-function inputs.
0.00
Hz
YesAAA28CH -
Reference
11
d1-12
Frequency
reference 12
The frequency reference
when multi-step speed com-
mands 1, 2, and 4 are ON for
multi-function inputs.
0.00
Hz
YesAAA28DH -
Reference
12
d1-13
Frequency
reference 13
The frequency reference
when multi-step speed com-
mands 3 and 4 are ON for
multi-function inputs.
0.00
Hz
YesAAA28EH -
Reference
13
d1-14
Frequency
reference 14
The frequency reference
when multi-step speed com-
mands 1, 3, and 4 are ON for
multi-function inputs.
0.00
Hz
YesAAA28FH -
Reference
14
d1-15
Frequency
reference 15
The frequency reference
when multi-step speed com-
mands 2, 3, and 4 are ON for
multi-function inputs.
0.00
Hz
Yes A A A 290H -
Reference
15
d1-16
Frequency
reference 16
The frequency reference
when multi-step speed com-
mands 1, 2, 3, and 4 are ON
for multi-function inputs.
0.00
Hz
Yes A A A 291H -
Reference
16
d1-17
Jog
frequency
reference
The frequency reference
when the jog frequency ref-
erence selection, FJOG com-
mand, or RJOG command is
ON.
6.00
Hz
Yes Q Q Q 292H
4-8
6-10
6-70
Jog
Reference
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
