Omron SYSDRIVE 3G3RV Series User Manual

P
arameter Tables
5
-
2
9
nReference Limits: d2
Parameters for frequency reference limits are shown in the following table.
nJump Frequencies: d3
Parameters for jump frequencies are shown in the following table.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
d2-01
Frequency
reference
upper limit
Set the output frequency
upper limit as a percent, tak-
ing the max. output fre-
quency to be 100%.
0.0 to
110.0
100.0% No A A A 289H
6-32
6-65
Ref Upper
Limit
d2-02
Frequency
reference
lower limit
Sets the output frequency
lower limit as a percentage
of the maximum output fre-
quency.
0.0 to
110.0
0.0% No A A A 28AH
6-32
6-65
Ref Lower
Limit
d2-03
Master
speed refer-
ence lower
limit
Set the master speed refer-
ence lower limit as a percent,
taking the max. output fre-
quency to be 100%.
0.0 to
110.0
0.0% No A A A 293H
6-32
6-65
Ref1 Lower
Limit
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
d3-01
Jump fre-
quency 1
Set the center values of the
jump frequencies in Hz.
This function is disabled by
setting the jump frequency to
0 Hz. Always ensure that the
following applies:
d3-01 ≥ d3-02 ≥ d3-03
Operation in the jump fre-
quency range is prohibited
but during acceleration and
deceleration, speed changes
smoothly without jump.
0.0 to
400.0
0.0 Hz No A A A 294H 6-29
Jump Freq 1
d3-02
Jump fre-
quency 2
0.0 Hz No A A A 295H 6-29
Jump Freq 2
d3-03
Jump fre-
quency 3
0.0 Hz No A A A 296H 6-29
Jump Freq 3
d3-04
Jump fre-
quency
width
Sets the jump frequency
bandwidth in Hz.
The jump frequency will be
the jump frequency ± d3-04.
0.0 to
20.0
1.0 Hz No A A A 297H 6-29
Jump Band-
width
