Omron SYSDRIVE 3G3RV Series User Manual

P
arameter Tables
5
-
3
3
*1.These are values for a 200-V class Inverter. Val ues for a 400-V class Inverter are double.
*2.The factory setting will change when the control method is changed. (V/f control factory settings are given.)
* 3. E1-11 and E1-12 are disregarded when set to 0.0.
*4.E1-13 is set to the same value as E1-05 by autotuning.
*5.When C6-01 is set to 0, the upper limit of the setting range is 150.0 Hz.
*6.For (-E) models. Factory setting for base frequency is 50 Hz.
nMotor Setup: E2
Parameters for motor 1 are shown in the following table.
E1-11
Mid.
output
frequency
2
Set only to fine-adjust V/f for the
output range. Normally, this setting
is not required.
0.0 to
400.0
0.0 Hz
*3
No A A A 30AH
6-129
Mid
Frequency
B
E1-12
Mid.
output
frequency
voltage 2
0.0 to
255.0
*1
0.0 V
*3
No A A A 30BH
6-129
Mid
Voltage B
E1-13
Base
voltage
0.0 to
255.0
*1
0.0 V
*4
No A A Q 30CH
6-129
Base
Voltage
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
E2-01
Motor rated
current
Sets the motor rated current
in 1 A units.
These set values will become
the reference values for
motor protection and torque
limits.
This parameter is automati-
cally set during autotuning.
0.32 to
6.40
*2
1.90 A
*1
No QQQ30EH
6-47
6-127
Motor
Rated FLA
E2-02
Motor rated
slip
Sets the motor rated slip in
Hz units.
These set values will become
the reference values for slip
compensation.
This parameter is automati-
cally set during autotuning.
0.00 to
20.00
2.90
Hz
*1
No A A A 30FH 6-127
Motor
Rated Slip
E2-03
Motor no-
load current
Sets the motor no-load cur-
rent in 1 A units.
This parameter is automati-
cally set during autotuning.
0.00 to
1.89
*3
1.20 A
*1
No A A A 310H 6-127
No-Load
Current
E2-04
Number of
motor poles
Sets the number of motor
poles.
This parameter is automati-
cally set during autotuning.
2 to 48 4 poles No No Q No 311H 6-127
Number of
Poles
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register
Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
