nAnalog Monitor Cards: F4
Parameters for the Analog Monitor Card are shown in the following table.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
F4-01
Channel 1
monitor
selection
Effective when the Analog
Monitor Card is used.
Monitor selection:
Set the number of the moni-
tor item to be output. (U1-
@@)
Gain:
Set the multiple of 10 V for
outputting monitor items.
4, 10 to 14, 28, 34, 39, 40
cannot be set. 17, 23, 25, 29,
30, 31, 35 are not used.
When the AO-12 Analog
Monitor Card is used, out-
puts of ± 10 V are possible.
To output ± 10 V, set F4-07
or F4-08 to 1. When the AO-
08 Analog Monitor Card is
used, only outputs of 0 to
+10 V are possible.
A meter calibration function
is available.
1 to 40 2 No
A
*
A
*
A
*
391H 6-73
AO Ch1
Select
F4-02
Channel 1
gain
0.00 to
2.50
1.00 Yes
A
*
A
*
A
*
392H 6-73
AO Ch1
Gain
F4-03
Channel 2
monitor
selection
1 to 40 3No
A
*
A
*
A
*
393H 6-73
AO Ch2
Select
F4-04
Channel 2
gain
0.00 to
2.50
0.50 Yes
A
*
A
*
A
*
394H 6-73
AO Ch2
Gain
F4-05
Channel 1
output mon-
itor bias
Sets the channel 1 item bias
to 100%/10 V when the Ana-
log Monitor Card is used.
-10.0 to
10.0
0.0 Yes
A
*
A
*
A
*
395H 6-73
AO Ch1
Bias
