Multi-function Digital Output Functions
H2-03
3G3RV
(Asia)
Terminal P2
function
select (con-
tact)
Multi-function
output 2
0 to 372 No AAA40DH -
Term P2 Sel
3G3RV
(-E)
(Europe)
Terminal
M5-M6
function
select (con-
tact)
Term M5-
M6 Sel
Set-
ting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
loop
Vec-
tor
0During run (ON: run command is ON or voltage is being output) Yes Yes Yes -
1 Zero-speed Yes Yes Yes -
2 Frequency agree 1 (L4-02 used.) Yes Yes Yes -
3
Desired frequency agree 1 (ON: Output frequency = ±L4-01, L4-02 used and dur-
ing frequency agree)
Yes Yes Ye s -
4
Frequency (FOUT) detection 1 (ON: +L4-01 ≥ output frequency ≥ -L4-01, L4-02
used)
Yes Yes Ye s -
5
Frequency (FOUT) detection 2 (ON: Output frequency ≥ +L4-01 or output fre-
quency ≤ -L4-01, L4-02 used)
Yes Yes Ye s -
6
Inverter operation ready
READY: After initialization, no faults
Yes Yes Ye s -
7During DC bus undervoltage (UV) detection Yes Yes Yes -
8During baseblock (ON: during baseblock) Yes Yes Yes -
9 Frequency reference selection (ON: Frequency reference from Operator) Yes Yes Yes -
ARun command selection status (ON: Run command from Operator) Yes Yes Yes -
B
Overtorque/undertorque detection 1 NO (NO contact: Overtorque/undertorque
detection at ON)
Yes Yes Ye s 6 -44
CLoss of frequency reference (Effective when 1 is set for L4-0 5) Yes Yes Ye s 6 -58
DBraking resistor fault (ON: Resistor overheat or braking transistor fa ul t) Yes Ye s Yes 6 -60
E
Fault (ON: Digital Operator communications error or fault other than CPF00 and
CPF01 has occurred.) (See Table 7.1 for faults.)
Yes Yes Ye s -
FNot used. (Set when the terminals are not used.) ----
10 Alarm (ON: Alarm displayed) (See Table 7.2 for alarms.) Yes Yes Yes -
11 Fault reset command ac ti ve Yes Yes Ye s -
12 Timer function output Yes Yes Yes
6-
116
13 Frequency agree 2 (L4-04 used) Yes Yes Yes -
Parameter Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
