nAnalog Inputs: H3
Parameters for analog inputs are shown in the following table.
14
Desired frequency agree 2 (ON: Output frequency = L4-03, L4-04 used, and dur-
ing frequency agree)
Yes Yes Yes -
15 Frequency detection 3 (ON: Output frequency ≤L4-03, L4-04 used) Yes Yes Yes -
16 Frequency detection 4 (ON: Output frequency ≥L4-03, L4-04 used) Yes Yes Yes -
17 Overtorque/undertorque detection 1 NC (NC Contact: Torque detection at OFF) Yes Yes Yes 6-44
18 Overtorque/undertorque detection 2 NO (NO Contact: Torque detection at ON) Yes Yes Yes 6-44
19 Overtorque/undertorque detection 2 NC (NC Contact: Torque detection at OFF) Yes Yes Yes 6-44
1A During reverse run (ON: During reverse run) Yes Yes Yes -
1B During baseblock 2 (OFF: During baseblock) Yes Yes Yes -
1C Motor selection (Motor 2 selected) Yes Yes Yes -
1D Not used (Set when the terminals are not used) Yes Yes Yes -
1E Restart enabled (ON: Restart enabled) Yes Yes Yes 6-58
1F
Motor overload (OL1, including OH3) pre-alarm (ON: 90% or more of the detec-
tion level)
Yes Yes Yes 6 -47
20 Inverter overheat (OH) pre-alarm (ON: Temperature exceeds L8-02 setting) Yes Yes Yes -
30 During torque limit (current limit) (ON: During torque limit) No No Yes -
37
During run 2 (ON: Frequency output, OFF: Base block, DC injection braking, ini-
tial excitation, operation stop)
Yes Yes Yes -
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
H3-01
Signal
select termi-
nal A1
(voltage)
0: Vol ta ge limit enabled
(Below 0 V is 0 V)
1:Voltage limit disabled
The setting value 1 can be
set for (-E) models.
0 or 10 No
A
*
A
*
A
*
410H -
Term A1
Lvl Sel
H3-02
Gain (termi-
nal A1)
Sets the frequency when 10
V is input, as a percentage of
the maximum output fre-
quency.
0.0 to
1000.0
100.0% Yes A A A 411H 6-27
Terminal
A1 Gain
H3-03
Bias (termi-
nal A1)
Sets the frequency when 0 V
is input, as a percentage of
the maximum frequency.
-100.0
to
+100.0
0.0% Yes A A A 412H 6-27
Terminal
A1 Bias
Set-
ting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
loop
Vec-
tor
