Omron SYSDRIVE 3G3RV Series

5
-
50
*For (-E) models.
H3-08
Multi-func-
tion analog
input termi-
nal A2 sig-
nal level
selection
0: Limit negative frequency
settings for gain and bias
settings to 0.
1: Do not limit negative
frequency settings for
gain and bias settings to 0
(i.e., allow reverse
operation).
2: 4 to 20 mA (9-bit input).
A switch for current or volt-
age input is located on the
terminal circuit board.
0 to 2 2 No A A A 417H 6-27
Term A2
Signal
H3-09
Multi-func-
tion analog
input termi-
nal A2 func-
tion
selection
Select multi-function analog
input function for terminal
A2. Refer to the next table.
0 to 1F 0 No A A A 418H 6-27
Terminal
A2 Sel
H3-10
Gain (termi-
nal A2)
Sets the input gain (level)
when terminal 14 is 10 V (20
mA).
Set according to the 100%
value for the function set for
H3-09.
0.0 to
1000.0
100.0% Yes A A A 419H 6-27
Terminal
A2 Gain
H3-11
Bias (termi-
nal A2)
Sets the input gain (level)
when terminal 14 is 0 V (4
mA).
Set according to the 100%
value for the function set for
H3-09.
-100.0
to
+100.0
0.0% Yes A A A 41AH 6-27
Terminal
A2 Bias
H3-12
Analog
input filter
time con-
stant
Sets primary delay filter time
constant in seconds for the
two analog input terminal
(A1 and A2).
Effective for noise control
etc.
0.00 to
2.00
0.00
s
No AAA41BH6-27
Filter Avg
Time
H3-13
Terminal
A1/A2
switching
0: Use terminal A1 analog
input as main speed
frequency reference.
1: Use terminal A2 analog
input as main speed
frequency reference.
Effective when H3-09 is set
to 2.
0 or 1 0 No AAA41CH -
TA1/A2
Select
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
