Omron SYSDRIVE 3G3RV Series

P
arameter Tables
5
-
5
1
H3-09 Settings
Set-
ting
Value
Function Contents (100%)
Control Methods
+1/
V/f
V/f
with
PG
Open
Loop
Vec-
tor
0Add to terminal A1 Maximum output frequency Yes Yes Yes 6-28
1 Frequency gain
Frequency reference (voltage) command
value
Yes Yes Yes 6 -28
2
Auxiliary frequency reference (2nd
step analog)
Maximum output frequency Yes Yes Yes 6-28
4 Voltage bias Motor rated voltage (E1-05) Yes Yes No -
5
Accel/decel change (reduction
coefficient)
Set acceleration and deceleration times (C1-
01 to C1-08)
Yes Yes Yes 6 -21
6DC injection braking current Inverter rated output current Yes Yes Yes 6-18
7
Overtorque/undertorque detection
level
Motor rated torque for vector control
Inverter rated output current for V/f control
Yes Yes Yes 6 -46
8 Stall prevention level during run Inverter rated output current Yes Yes No 6-43
9
Frequency reference lower limit
level
Maximum output frequency Yes Yes Yes 6-33
AJump frequency Maximum output frequency Yes Yes Yes 6-30
BPID feedback Maximum output frequency Yes Yes Yes
6-
120
CPID target value Maximum output frequency Yes Yes Yes
6-
120
EMotor temperature input 10 V = 100% Yes Yes Yes 6-51
10 Positive torque limit Motor's rated torque No No Yes 6-40
11 Negative torque limit Motor's rated torque No No Yes 6-40
12 Regenerative torque limit Motor's rated torque No No Yes 6-40
15 Positive/negative torque limit Motor's rated torque No No Yes 6-40
1F Analog input not used. - Yes Yes Yes
13, 14,
16 to 1F
Not used - - - - -
