*For (-E) models. The shunt connector CN15 must be set. For details, refer to page 2-43.
nRS-422A/485 Communications: H5
Parameters for RS-422A/485 communications are shown in the following table.
H4-08
Analog out-
put 2 signal
level selec-
tion
Sets the signal output level
for multi-function output 2
(terminal AM)
0:0 to +10 V output
1:0 to ±10 V output
(2: 4 to 20 mA)
*
0 or 1
(0 to 2)
*
0 No A A A 424H 6-72
AO Level
Select2
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
H5-01
Slave
address
Set the Inverter's slave
address.
0 to 20
*
1F No A A A 425H 6-76
Serial
Comm Adr
H5-02
Communi-
cation speed
selection
Set the baud rate for 6CN
RS-422A/485 communica-
tions.
0:1200 bps
1:2400 bps
2:4800 bps
3:9600 bps
4:19200 bps
0 to 4 3 No A A A 426H 6-76
Serial Baud
Rate
H5-03
Communi-
cation parity
selection
Set the parity for 6CN RS-
422A/485 communications.
0:No parity
1:Even parity
2:Odd parity
0 to 2 0 No A A A 427H 6-76
Serial Com
Sel
H5-04
Stopping
method
after com-
munication
error
Set the stopping method for
RS-422A/485 communica-
tions error.
0:Deceleration to stop
using deceleration time in
C1-02
1:Coast to stop
2:Emergency stop using
deceleration time in C1-
09
3:Continue operation
0 to 3 3 No A A A 428H 6-76
Serial Fault
Sel
H5-05
Communi-
cation error
detection
selection
Set whether or not a commu-
nications timeout is to be
detected as a communica-
tions error (CE).
0:Do not detect.
1:Detect
0 or 1 1 No A A A 429H 6-76
Serial Flt
Dtct
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register
Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
