*Set H5-01 to 0 to disable Inverter responses to RS-422A/485 communications.
nPulse Train I/O: H6
Parameters for pulse I/O are shown in the following table.
H5-06
Send wait
time
Set the time from the
Inverter receiving data to
when the Inverter starts to
send.
5 to 65 5 msNo AAA42AH6-76
Transmit
WaitTIM
H5-07
RTS con-
trol ON/
OFF
Select to enable or disable
RTS control.
0: Disabled (RTS is always
ON)
1: Enabled (RTS turns ON
only when sending)
0 or 1 1 No AAA42BH6-76
RTS Con-
trol Sel
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
H6-01
Pulse train
input func-
tion selec-
tion
0: Frequency reference
1: PID feedback value
2: PID target value
0 to 2 0 No AAA42CH
6-6
6-30
6-119
Pulse Input
Sel
H6-02
Pulse train
input scal-
ing
Set the number of pulses in
hertz, taking the reference to
be 100%.
1000 to
32000
1440
Hz
YesAAA42DH
6-6
6-30
Pulse In
Scaling
H6-03
Pulse train
input gain
Set the input gain level as a
percent when the pulse train
set in H6-02 is input.
0.0 to
1000.0
100.0% Yes A A A 42EH 6-30
Pulse Input
Gain
H6-04
Pulse train
input bias
Set the input bias when the
pulse train is 0.
-100.0
to
100.0
0.0% Yes A A A 42FH 6-30
Pulse Input
Bias
H6-05
Pulse train
input filter
time
Set the pulse train input pri-
mary delay filter time con-
stant in seconds.
0.00 to
2.00
0.10
s
Yes A A A 430H 6-30
Pulse In Fil-
ter
H6-06
Pulse train
monitor
selection
Select the pulse train moni-
tor output items (value of the
oo part of U1-oo).
There are two types of moni-
tor items: Speed-related
items and PID-related items.
1, 2, 5,
20, 24,
36
2 Yes A A A 431H 6-74
Pulse Moni
Sel
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
