nTorque Limits: L7
Parameters for torque limits are shown in the following table.
nHardware Protection: L8
Parameters for hardware protection functions are shown in the following table.
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register
Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
L7-01
Forward
drive
torque
limit
Sets the torque limit value as a per-
centage of the motor rated torque.
Four individual regions can be set.
0 to
300
200% No No No A 4A7H 6-40
Torq Limit
Fwd
L7-02
Reverse
drive
torque
limit
0 to
300
200% No No No A 4A8H 6-40
Torq Limit
Rev
L7-03
Forward
regenera-
tive torque
limit
0 to
300
200% No No No A 4A9H 6-40
Torq Lmt
Fwd Rgn
L7-04
Reverse
regenera-
tive torque
limit
0 to
300
200% No No No A 4AAH 6-40
Torq Lmt
Rev Rgn
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
L8-01
Protect
selection for
internal DB
resistor
0:Disabled (no overheating
protection)
1:Enabled (overheating
protection)
0 or 1 0 No A A A 4ADH 6-60
DB Resis-
tor Prot
L8-02
Overheat
pre-alarm
level
Sets the detection tempera-
ture for the Inverter overheat
detection pre-alarm in °C.
The pre-alarm detects when
the cooling fin temperature
reaches the set value.
50 to
130
95 °C* No A A A 4AEH 6-61
OH Pre-
Alarm Lvl
Output torque
Positive torque
Reverse
Negative torque
No. of
motor
rotations
Regenerative
state
Regenerative
state
Forward
