Omron SYSDRIVE 3G3RV Series User Manual

5
-
66
L8-03
Operation
selection
after over-
heat pre-
alarm
Sets the operation for when
the Inverter overheat pre-
alarm goes ON.
0:Decelerate to stop in
deceleration time C1-02.
1: Coast to stop
2: Fast stop in fast-stop time
C1-09.
3: Continue operation
(Monitor display only.)
A fault will be given in set-
ting 0 to 2 and a minor fault
will be given in setting 3.
0 to 3 3 No A A A 4AFH 6-61
OH Pre-
Alarm Sel
L8-05
Input open-
phase pro-
tection
selection
0: Disabled
1: Enabled (Detects if input
current open-phase,
power supply voltage
imbalance or main circuit
electrostatic capacitor
deterioration occurs.)
0 or 1
0
(1)
*
No A A A 4B1H -
Ph Loss In
Sel
L8-07
Output
open-phase
protection
selection
0: Disabled
1: Enabled (Output open-
phase detected at less
than 5% of Inverter rated
current.)
When applied motor capac-
ity is small for Inverter
capacity, output open-phase
may be detected inadvert-
ently or open-phase may not
be detected. In this case, set
to 0.
0 or 1
0
No A A A 4B3H -
Ph Loss Out
Sel
L8-09
Ground pro-
tection
selection
0:Disabled
1:Enabled
0 or 1 1 No A A A 4B5H -
Ground
Fault Sel
L8-10
Cooling fan
control
selection
Set the ON/OFF control for
the cooling fan.
0: ON only when Inverter is
ON
1: ON whenever power is
ON
0 or 1 0 No A A A 4B6H -
Fan On/Off
Sel
L8-11
Cooling fan
control
delay time
Set the time in seconds to
delay turning OFF the cool-
ing fan after the cooling fan
OFF command is received.
0 to
300
60 s No A A A 4B7H -
Fan Delay
Time
L8-12
Ambient
temperature
Set the ambient temperature.
No need to change the set-
tings for normal usage.
45 to
60
45 °C No A A A 4B8H -
Ambient
Temp
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
