Omron SYSDRIVE 3G3RV Series User Manual

P
arameter Tables
5
-
7
1
nMulti-function Selections: o2
Parameters for Digital Operator key functions are shown in the following table.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
o2-01
LOCAL/
REMOTE
key enable/
disable
Sets the Digital Operator
Local/Remote Key
0:Disabled
1:Enabled (Switches
between the Digital
Operator and the parame-
ter settings.)
0 or 1 1 No A A A 505H 6-135
Local/
Remote Key
o2-02
STOP key
during con-
trol circuit
terminal
operation
Sets the Stop Key in the run
mode.
0:Disabled (When the run
command is issued from
and external terminal, the
Stop Key is disabled.)
1:Enabled (Effective even
during run.)
0 or 1 1 No A A A 506H 6-135
Oper STOP
Key
o2-03
Parameter
initial value
Clears or stores user initial
values.
0:Stores/not set
1:Begins storing (Records
the set parameters as user
initial values.)
2:All clear (Clears all
recorded user initial
values)
When the set parameters are
recorded as user initial val-
ues, 1110 will be set in A1-
03.
0 to 2 0 No A A A 507H 6-135
User
Defaults
o2-04
kVA selec-
tion
Do not set unless using a
control board from an
Inverter with a different
capacity.
0 to FF
0
*1
No AAA508H -
Inverter
Model#
o2-05
Frequency
reference
setting
method
selection
When the frequency refer-
ence is set on the Digital
Operator frequency refer-
ence monitor, sets whether
the Enter Key is necessary.
0:Enter Key needed
1:Enter Key not needed
When set to 1, the Inverter
accepts the frequency refer-
ence without Enter Key
operation.
0 or 1 0 No A A A 509H 6-135
Operator
M.O.P.
