5
-
72
*1.The factory setting depends upon the Inverter capacity. The value for a 200-V class Inverter of 0.4 kW is given.
*2.For (-E) models.
o2-06
Operation
selection
when digi-
tal operator
is discon-
nected
Sets the operation when the
Digital Operator is discon-
nected.
0: Disabled (Operation
continues even if the
Digital Operator is
disconnected.)
1: Enabled (OPR is detected
at Digital Operator
disconnection. Inverter
output is cut off, and fault
contact is operated.)
0 or 1
0
No AAA50AH -
Oper Detec-
tion
o2-07
Cumulative
operation
time setting
Sets the cumulative opera-
tion time in hour units.
Operation time is calculated
from the set values.
0 to
65535
0 hr No A A A 50BH 6-135
Elapsed
Time Set
o2-08
Cumulative
operation
time selec-
tion
0: Cumulative time when
the Inverter power is on.
(All time while the
Inverter power is on is
accumulated.)
1: Cumulative Inverter run
time. (Only Inverter
output time is
accumulated.)
0 or 1
0
(1)
*2
No AAA50CH -
Elapsed
Time Run
o2-09
Factory use
Do not change. - - No
AAA
--
Init Mode
Sel
o2-10
Fan opera-
tion time
setting
Set the initial value of the
fan operation time using
time units.
The operation time accumu-
lates from the set value.
0 to
65535
0 hr No A A A 50EH 6-135
Fan ON
Time Set
o2-12
Fault trace/
fault his-
tory initial-
ization
0: Disable (U2, U3 are held)
1: Enable (U2, U3 are ini-
tialized and o2-12 returns
to 0.) For (-E) models
only.
0 or 10 No
A
*2
A
*2
A
*2
510H -
FLT Trace
Init
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
