Omron SYSDRIVE 3G3RV Series User Manual

5
-
78
U1-27
Output volt-
age refer-
ence (Vd)
Monitors the Inverter inter-
nal voltage reference for
motor excitation current con-
trol.
10 V: 200 VA C (400 VAC)
(0 to ± 10 V possible)
0.1
V
No No A 5AH
Vo l t ag e Ref
(Vd)
U1-28
Software
No. (CPU)
(Manufacturer’s CPU soft-
ware No.)
(Cannot be output.) - A A A 5BH
CPU ID
U1-32
ACR out-
put of q axis
Monitors the current control
output value for the motor
secondary current.
10 V: 100%
(0 to ± 10 V possible)
0.1
%
No No A 5FH
ACR (q)
Output
U1-33
ACR out-
put of d axis
Monitors the current control
output value for the motor
excitation current.
10 V: 100%
(0 to ± 10 V possible)
0.1
%
No No A 60H
ACR (d)
Output
U1-34
OPE fault
parameter
Shows the first parameter
number where an OPE fault
was detected.
(Cannot be output.) - A A A 61H
OPE
Detected
U1-36
PID input
volume
PID feedback volume
Given as maximum fre-
quency/100%
10 V: Max. frequency
(0 to ± 10 V possible)
0.01
%
AAA 63H
PID Input
U1-37
PID output
volume
PID control output
Given as maximum fre-
quency/100%
10 V: Max. frequency
(0 to ± 10 V possible)
0.01
%
AAA 64H
PID Output
U1-38
PID com-
mand
PID command + PID com-
mand bias
Given as maximum fre-
quency/100%
10 V: Max. frequency
0.01
%
AAA 65H
PID Set-
point
U1-39
RS-422A/
485 Com-
munica-
tions Error
Shows RS-422A/485 com-
munications errors.
(Cannot be output.) - A A A 66H
Transmit
Err
U1-40
Cooling fan
operating
time
Monitors the total operating
time of the cooling fan. The
time can be set in 02-10.
(Cannot be output.)
1
hr
AAA 68H
FAN
Elapsed
Time
Param-
eter
Number
Name
Description
Output Signal Level Dur-
ing Multi-Function Analog
Output
Min.
Unit
Control Methods
Register
LCD
Display
V/f
V/f
with
PG
Open
Loop
Vec-
tor
1: CRC error
1: Data length error
Not used (always 0).
1: Parity
error
1: Overrun
error
1: Framing
error
1:
Timeout
Not used
(
alwa
y
s 0
)
.
U1-40=
