Omron SYSDRIVE 3G3RV Series

C
ommunications Functions
6
-
8
7
002CH
Inverter status
Bit 0
Operation 1: Operating
Bit 1
Zero speed 1: Zero speed
Bit 2
Frequency matching 1: Matched
Bit 3
User-defined speed matching 1: Matched
Bit 4
Frequency detection 11: Output frequency ≤ L4-01
Bit 5
Frequency detection 2 Output frequency ≥ L4-01
Bit 6
Inverter startup completed 1: Startup completed
Bit 7Low voltage detection 1: Detected
Bit 8
Baseblock 1: Inverter output baseblock
Bit 9
Frequency reference mode 1: Not communications 0: Communications
Bit A
Run command mode 1: Not communications 0: Communications
Bit B
Overtorque detection 1: Detected
Bit C
Frequency reference lost 1: Lost
Bit DRetrying error 1: Retrying
Bit EError (including RS-422A/485 communications time-out) 1:Error occurred
Bit F Communications time-out 1: Timed out
002DH
Multi-function output status
Bit 0 Multi-function output (terminal M1-M2) 1: ON 0: OFF
Bit 1 Multi-function output 1 (terminal P1-PC, M3-M4): 1: ON 0: OFF
Bit 2 Multi-function output 2 (terminal P1-PC, M5-M6): 1: ON 0: OFF
Bits 3 to FNot used
002EH - 0030H Not used
0031H Main circuit DC voltage
0032H - 0037H Not used
0038H PID feedback quantity (Input equivalent to 100%/Max. output frequency; 10/1%; without sign)
0039H PID input quantity (±100%/±Max. output frequency; 10/1%; with sign)
003AH PID output quantity (±100%/±Max. output frequency; 10/1%; with sign)
003BH CPU software number
003CH Flash software number
003DH
Communications error details
Bit 0 CRC error
Bit 1 Invalid data length
Bit 2Not used
Bit 3Parity error
Bit 4 Overrun error
Bit 5Framing error
Bit 6Time-out
Bits 7 to FNot used
Register No. Contents
