nData
Created
by
Protocol
Support
Tool
and
CX-Protocol
Fig 6.65 Project File Configuration
The
standard
system
protocol
incorporated
by
the
Communications
Board
cannot
be
edited
or
transferred.
To
make
use
of
the
standard
system
protocol,
copy
it
to
the
project
file
and
edit
it.
Under
Creating
a
Project
File,
an
example
to
create
a
new
project
file
is
shown
without
making
use
of
the
standard
system
protocol.
Single project file
Protocol list
Trace list
PC
Protocol name
Protocol name
Protocol name
A maximum of 20 protocols
(A maximum of 1,000 sequences per project)
Protocol name
(Single protocol)
Sequence
Sequence 000/Sequence name
Sequence 001/Sequence name
Sequence 999/Sequence name
Send message list
A maximum of 60 sequences/protocol
The first sequence number and last sequence number
are specified by each protocol.
Message name
Message name
Recv message list Message name
Message name
Recv matrix Matrix name
Matrix name
A maximum of 300 messages
A maximum of 100 matrixes
Step 00
Step 01
Step 15
A maximum of 16 steps
