Omron SYSDRIVE 3G3RV Series User Manual

6
-
118
nRelated Parameters
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
b5-01
PID control mode selection
0: Disabled
1: Enabled (Deviation is D-controlled.)
2: Enabled (Feedback value is D-controlled.)
3: PID control enabled (frequency reference +
PID output, D control of deviation)
4: PID control enabled (frequency reference +
PID output, D control of feedback value).
0 to 40 NoAAA
PID Mode
b5-02
Proportional gain (P)
Sets P-control proportional gain as a percentage.
P-control is not performed when the setting is
0.00.
0.00
to
25.00
1.00 Yes A A A
PID Gain
b5-03
Integral (I) time
Sets I-control integral time in 1-second units.
I-control is not performed when the setting is 0.0.
0.0 to
360.0
1.0 sYesAAA
PID I Time
b5-04
Integral (I) limit
Sets the I-control limit as a percentage of the
maximum output frequenc.
0.0 to
100.0
100.0% Yes A A A
PID I Limit
b5-05
Derivative (D) time
Sets D-control derivative time in 1-second units.
D-control is not performed when the setting is
0.00.
0.00 to
10.00
0.00 sYes AAA
PID D Time
b5-06
PID limit
Sets the limit after PID-control as a percentage of
the maximum output frequency.
0.0 to
100.0
100.0% Yes A A A
PID Limit
b5-07
PID offset adjustment
Sets the offset after PID-control as a percentage
of the maximum outut frequency.
-100.0
to
+100.0
0.0% Yes A A A
PID Offset
b5-08
PID primary delay time
constant
Sets the time constant for low pass filter for PID-
control outputs in 1-second units.
Not usually necessary to set.
0.00 to
10.00
0.00 sYes AAA
PID Delay Time
b5-09
PID output characteristics
selection
Select forward/reverse for PID output.
0: PID output is forward.
1: PID output is reverse (highlights the output
code)
0 or 10 NoAAA
Output Level Sel
b5-10
PID output gain
Sets output gain.
0.0 to
25.0
1.0 No A A A
Output Gain
b5-11
PID reverse output selection
0: 0 limit when PID output is negative.
1: Reverse when PID output is negative.
0 limit when reverse prohibit is selected using b1-
04.
0 or 10 NoAAA
Output Rev Sel
b5-12
Selection of PID feedback
command loss detection
0: No detection of loss of PID feedback
1: Detection of loss of PID feedback. Operation
continues during detection, with the malfunc-
tioning contact not operating.
2: Detection of loss of PID feedback. Coasts to
stop during detection, and fault contact
0 to 20 NoAAA
Fb los Det Sel
b5-13
PID feedback command
loss detection level
Set the PID feedback loss detection level as a per-
cent, with the maximum output frequency at
100%.
0 to 100 0% No A A A
Fb los Det Lvl
b5-14
PID feedback command
loss detection time
Sets the PID feedback loss detection level in s
units.
0.0 to
25.5
1.0 sNoAAA
Fb los Det Time
b5-15
PID sleep function opera-
tion level
Set the PID sleep function start level as a fre-
quency.
0.0 to
400.0
0.0 Hz No A A A
PID Sleep Level
