Multi-Function Digital Inputs (H1-01 to H1-05)
Multi-Function Analog Input (H3-09)
b5-16
PID sleep operation delay
time
Set the delay time until the PID sleep function
starts in seconds.
0.0 to
25.5
0.0 sNoAAA
PID Sleep Time
b5-17
Accel/decel time for PID
reference
Set the accel/decel time for PID reference in sec-
onds.
0.0 to
25.5
0.0 sNoAAA
PID Acc/Dec Time
b5-18
PID set point selection
0: PID set point disabled
1: PID set point enabled
0 or 10 No
A
*
A
*
A
*
PID Setpoint Sel
b5-19
PID set point
PID set point
0.0 to
100.0
0.0% No
A
*
A
*
A
*
PID Setpoint
H6-01
Pulse train input function
selection
0: Frequency reference
1: PID feedback value
2: PID target value
0 to 20 NoAAA
Pulse Input Sel
Param-
eter
Num-
ber
Name
Description
Output Signal Level During
Multi-Function Analog Output
Min.
Unit
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
U1-24
PID feedback value
Monitors the feedback value when
PID control is used.
The input for the max. frequency cor-
responds to 100%.
10 V: Max. frequency (0 to ± 10 V
possible)
0.01% A A A
PID Feedback
U1-36
PID input volume
PID feedback volume
Given as maximum frequency/100%
10 V: Max. frequency (0 to ± 10 V
possible)
0.01% A A A
PID Input
U1-37
PID output volume
PID control output
Given as maximum frequency/100%
10 V: Max. frequency (0 to ± 10 V
possible)
0.01% A A A
PID Output
U1-38
PID command
PID command + PID command bias
Given as maximum frequency/100%
10 V: Max. frequency 0.01% A A A
PID Setpoint
Set
Value
Function
Control Methods
V/f
V/f
with
PG
Open
loop
Vec-
tor
19 PID control disable (ON: PID control disabled) Yes Yes Yes
30 PID control integral reset (reset when reset command is input or when stopped during PID control) Yes Yes Yes
31 PID control integral hold (ON: Integral hold) Yes Yes Yes
34 PID soft starter Yes Ye s Yes
35 PID input characteristics switch Yes Ye s Yes
Set
Value
Function
Control Methods
V/f
V/f
with
PG
Open
loop
Vec-
tor
BPID feedback Max. output frequency Yes Yes Yes
CPID target value Max. output frequency Yes Yes Yes
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
