6
-
120
nPID
Control
Methods
There
are
four
PID
control
methods.
Select
the
method
by
setting
parameter
b5-01.
nPID
Input
Methods
Enable
PID
control
using
parameter
b5-01,
and
set
the
PID
target
value
and
PID
feedback
value.
PID
Target
Value
Input
Methods
Select
the
PID
control
target
value
input
method
according
to
the
setting
in
b1-01
(Reference
Selection).
Normally,
the
frequency
reference
selected
in
b1-01
is
the
PID
target
value,
but
you
can
also
set
the
PID
target
value
as
shown
in
the
following
table.
PID
Feedback
Input
Methods
Select
one
of
the
following
PID
control
feedback
input
methods.
nPID
Adjustment
Methods
Use
the
following
procedure
to
adjust
PID
while
performing
PID
control
and
measuring
the
response
wave-
form.
1. Set
b5-01
(PID
Control
Mode
Selection)
to
1,
2,
3
or
4
(PID
control
enabled).
2. Increase
b5-02
(Proportional
Gain
(P))
to
within
a
range
that
does
not
vibrate.
3. Reduce
b5-03
(Integral
(I)
time)
to
within
a
range
that
does
not
vibrate.
4. Increase
b5-05
(Derivative
(D)
time)
to
within
a
range
that
does
not
vibrate.
Set
Value Control
Method
1
PID
output
becomes
the
Inverter
output
frequency,
and
D
control
is
used
in
the
difference
between
PID
target
value
and
feedback
value.
2PID
output
becomes
the
Inverter
output
frequency,
and
D
control
is
used
in
the
PID
feedback
value.
3
PID
output
is
added
as
compensation
value
of
the
Inverter
output
frequency,
and
D
control
is
used
in
the
difference
between
PID
target
value
and
feedback
value.
4
PID
output
is
added
as
compensation
value
of
the
Inverter
output
frequency,
and
D
control
is
used
in
the
PID
feedback
value.
PID
Target
Input
Method Setting
Conditions
Multi-Function
Analog
Ter-
minal
A2
Input
Set
H3-09
to
C
(PID
target
value).
Also,
be
sure
to
set
H6-01
(pulse
train
input
function
selection)
to
1
(PID
feedback
value).
RS-422A/485
register
0006H
Set
RS-422A/485
bit
1
in
register
address
000FH
to
1
(enable/disable
PID
target
value
from
communications)
to
be
able
to
use
register
number
0006H
as
the
PID
target
value.
Pulse
train
input Set
H6-01
to
2
(PID
target
value).
Input
Method Setting
Conditions
Multi-function
analog
input Set
H3-09
(Multi-function
Analog
Input
Terminal
A2
Selection)
to
B
(PID
feedback).
Pulse
train
input Set
H6-01
to
1
(PID
feedback).
INFO
Adjust PID target value and PID feedback value using the following items.
•Analog
input:
Adjust
using
the
analog
input
terminal
gain
and
bias.
•Pulse
train
input:
Adjust
using
pulse
train
scaling,
pulse
train
input
gain,
and
pulse
train
input
bias.
