*1.The default settings are given for terminals S3 to S7. For a 3-wire sequence, the default settings are a 3-wire sequence for S5, multi-step speed setting 1
for S6 and multi-step speed setting 2 for S7.
*2.When driving a reactive load, such as a relay coil, always insert a flywheel diode as shown in Fig 2.31.
*3.Pulse input specifications are given in the following table.
Fig 2.31 Flywheel Diode Connection
Analog
output
signals
FM
Multi-function analog output
(frequency output)
0 to +10 V/100% fre-
quency
Multi-function
analog monitor 1
0 to +10 V max. ±5%
2 mA max.
AC Analog common (copy) -
AM
Multi-function analog output
(current monitor)
5 V/Inverter's rated cur-
rent
Multi-function
analog monitor 2
Pulse
I/O
RP
Pulse input
*3
H6-01 (Frequency reference input)
0 to 32 kHz (3 kΩ)
High level voltage 3.5 to
13.2 V
MP Pulse monitor H6-06 (Output frequency)
0 to 32 kHz
+5 V output
(Load: 1.5 kΩ)
RS-
485/
422A
R+
RS-422A/485 communica-
tions input
For 2-wire RS-485, short R+ and S+ as well
as R- and S-.
Differential input,
photocoupler isolation
R-
S+
RS-422A/485 communica-
tions output
Differential input,
photocoupler isolation
S-
IG Signal common - -
Low level voltage 0.0 to 0.8 V
High level voltage 3.5 to 13.2 V
H duty 30% to 70%
Pulse frequency 0 to 32 kHz
Table 2.21 Control Circuit Terminals (Continued)
Type No. Signal Name Function Signal Level
External power:
48 V max.
Coil
Flywheel diode
50 mA max.
The rating of the flywheel diode
must be at least as high as the
circuit voltage.
