iring Control Circuit Terminals for European Models
2
-
4
3
nShunt Connector CN15 and DIP Switch S1
The shunt connector CN 15 and DIP switch S1 are described in this section.
Fig 2.32 Shunt Connector CN15 and DIP Switch S1
The functions of DIP switch S1 are shown in the following table.
Table 2.22 DIP Switch S1
Name Function Setting
S1-1
RS-485 and RS-422A terminating resis-
tance
OFF: No terminating resistance
ON: Terminating resistance of 110 Ω
S1-2 Input method for analog input A2
OFF: 0 to 10 V (internal resistance: 20 kΩ)
ON: 4 to 20 mA (internal resistance: 250 Ω)
S1
O
F
F
1
2
CN15
Note: Refer to Table 2.13 for S1
functions
Current output
Voltage output (Factory setting)
Analog output switch
Terminating resistance
Analog input A2 swich
CN15
S1
: Factory settings
OFF ON
VI
