Sinking/Sourcing
Mode
The
input
terminal
logic
can
be
selected
between
sinking
mode
(0-V
common)
and
sourcing
mode
(+24-V
common)
as
shown
in
Table
2.23.
An
external
power
supply
is
also
supported,
providing
more
freedom
in
sig-
nal
input
methods.
Table 2.23 Sinking/Sourcing Mode and Input Signals
Internal
Power
Supply External
Power
Supply
Sink-
ing
Mode
Sourc-
ing
Mode
S1
S2
SC
SN
SP
IP24V (+24V)
S1
S2
SC
SN
SP
IP24V (+24V)
External
+24V
S1
S2
SC
SN
SP
IP24V (+24V)
S1
S2
SC
SN
SP
IP24V (+24V)
External
+24V
