474
Instruction
OFF execution time (µs)ON execution time (µs)
ConditionsWords
CV1000*CV500*CV1000*CV500*
!CMP(020) 4 Additional time over CMP(020) for
each input word being compared
+5.5 +5.0 1.05 0.88
Additional time over CMP(020) for
each output word being compared
+4.4 +4.0
Additional time over CMP(020) for
words other than I/O words
+0 +0
CMPL(021) 4 When comparing two words 5.1 4.3 1.2 1.0
When comparing two *DM
8.1 6.8
BCMP(022) 5 Comparing constant to table with
results to a word
20.3 16.9 1.35 1.13
Comparing *DM to table with results
to *DM
24.3 20.3
TCMP(023) 5 When comparing a word to a word
table
17.9 14.9
When comparing a *DM to *DM table
21.9 18.3
MCMP(024) 5 When comparing two words 20.6 17.3
When comparing two *DM
24.2 20.3
EQU(025) 4 Comparing two words 3.8 3.1
1.2 1.0
Comparing two *DM
6.9 5.8
CPS(026) 4 Comparing constants and words 4.2 3.5
Comparing two *DM
7.5 6.25
!CPS(026) 4 Amount added per input word at time
of comparison
+5.5 +5.0
Amount added per output word at
time of comparison
+4.4 +4.0
Other areas at time of comparison +0 +0
CPSL(027) 4 Comparing constants and words 5.4 4.5
Comparing two *DM
8.25 6.88
CMP(028) 4 Comparing constants and words 3.9 3.3
1.05
0.88
Comparing two *DM
7.1 5.9
!CMP(028) 4 Amount added per input word at time
of comparison
+5.5 +5.0
Amount added per output word at
time of comparison
+4.4 +4.0
Other areas at time of comparison +0 +0
CMPL(029) 4 Comparing two words 5.1 4.3
1.2 1.0
Comparing two *DM
8.1 6.8
MOV(030) 4 When transferring a constant to a
word
5.1 4.3
When transferring *DM to *DM
6.3 5.3
!MOV(030) Additional time over MOV(020) for
each input word being used
+5.5 +5.0
Additional time over MOV(020) for
each output word being used
+4.4 +4.0
Additional time over MOV(020) for
words other than I/O words
+0 +0
MVN(031) 4 When transferring a constant to a
word
5.3 4.4
When transferring *DM to *DM
6.5 5.4
MOVL(032) 4 When transferring a word to a word 6.5 5.4
When transferring *DM to *DM
7.5 6.3
*Note: CV500 = CV500 or CVM1-CPU01-EV2; CV1000 = CV1000, CV2000, or CVM1-CPU11/21-EV2
Instruction Execution Times Section 6-4
