477
Instruction
OFF execution time (µs)ON execution time (µs)
ConditionsWords
CV1000*CV500*CV1000*CV500*
*DM ÷ *DM → *DM
25.4 21.1
ADDL(074) 5 Constant + word → word 21.8 18.0 1.35 1.13
*DM + *DM → *DM
25.8 21.5
SUBL(075) 5 Constant – word → word 21.0 17.5
*DM – *DM → *DM
25.2 21.0
MULL(076) 5 Constant x word → word 64.5 53.8
*DM x *DM → word
68.7 57.3
DIVL(077) 5
Word ÷ constant → word
74.6 62.1
*DM ÷ *DM → *DM
78.6 65.5
STC(078) 2 --- 1.65 1.38 0.9 0.75
CLC(079) 2 --- 1.65 1.38
ADB(080) 5 Constant + word → word 7.2 6.0 1.35 1.13
*DM + *DM → *DM
11.6 9.6
SBB(081) 5 Constant – word → word 7.4 6.1
*DM – *DM → *DM
11.7 9.8
MLB(082) 5 Constant x word → word 15.8 13.1
*DM x *DM → word
20.1 16.8
DVB(083) 5
Word ÷ constant → word
19.1 15.9
*DM ÷ *DM → *DM
23.4 19.5
ADBL(084) 5 Constant + word → word 9.2 7.6
*DM + *DM → *DM
13.4 11.1
SBBL(085) 5 Constant – word → word 9.3 7.8
*DM – *DM → *DM
13.5 11.3
MLBL(086) 5 Constant x word → word 46.1 38.4
*DM x *DM → word
50.3 41.9
DVBL(087) 5
Word ÷ constant → word
57.3 47.8
*DM ÷ *DM → *DM
61.5 51.3
INC(090) 3 Word increment 6.3 5.3 1.05 0.88
*DM increment
7.5 6.3
DEC(091) 3 Word decrement 6.5 5.4
*DM decrement
7.7 6.4
INCB(092) 3 Word increment 5.6 4.6
*DM increment
6.8 5.6
DECB(093) 3 Word decrement 5.9 4.9
*DM decrement
7.1 5.9
INCL(094) 3 Word increment 15.5 12.9
*DM increment
16.7 13.9
DECL(095) 3 Word decrement 15.3 12.8 1.05 0.875
*DM decrement
16.5 13.8
INBL(096) 3 Word increment 6.8 5.6
*DM increment
8.0 6.6
DCBL(097) 3 Word decrement 6.9 5.8
*DM decrement
8.0 6.6
BIN(100) 4 When converting a word to a word 6.2 5.1 1.2 1.0
When converting *DM to *DM
8.6 7.1
BCD(101) 4 When converting a word to a word 6.0 5.0
*Note: CV500 = CV500 or CVM1-CPU01-EV2; CV1000 = CV1000, CV2000, or CVM1-CPU11/21-EV2
Instruction Execution Times Section 6-4
