478
Instruction
OFF execution time (µs)ON execution time (µs)
ConditionsWords
CV1000*CV500*CV1000*CV500*
When converting *DM to *DM
8.4 7.0
BINL(102) 4 When converting a word to a word 10.2 8.5 1.2 1.0
When converting *DM to *DM
12.6 10.5
BCDL(103) 4 When converting a word to a word 11.6 9.6
When converting *DM to *DM
14.0 11.6
NEG(104) 4 When converting a word to a word 5.7 4.8
When converting *DM to *DM
8.3 6.9
NEGL(105) 4 When converting a word to a word 7.1 5.9
When converting *DM to *DM
9.5 7.9
SIGN(106) 4 When expanding a word to a word 6.6 5.5
When expanding *DM to *DM
9.0 7.5
MLPX(110) 5 When decoding a word to a word 7.2 6.0 1.35 1.13
When decoding *DM to *DM
15.6 13.0
DMPX111) 5 When encoding a word to a word 9.8 8.1
When encoding *DM to *DM
16.2 13.5
SDEC(112) 5 When decoding a word to a word 317 264
When decoding *DM to *DM
424 353
ASC(113) 5 Word → word 324 270
*DM → *DM
431 359
BCNT(114) 5 When counting 1 word 412 344
When counting 1000 words with *DM
20.5 ms 17.1 ms
LINE(115) 5 When converting word to word using
constant specification
14.0 11.6
When converting *DM to *DM with
DM specification
18.0 15.0
COLM(116) 5 When converting word to word using
constant specification
25.1 20.9
When converting *DM to *DM with
DM specification
29.4 24.5
HEX(117) 5 Converting 1 digit, word → word 20.6 17.1
Converting 4 digits, *DM → *DM
48.6 40.5
TTIM(120) 4 Constant for SV 11.1 9.3 R: 9.8
IL: 3.0
R: 8.1
IL: 2.5
*DM for SV
12.8 10.6 R: 11.4
IL: 3.0
R: 9.5
IL: 2.5
TIML(121) 5 --- 1.71 ms 1.42 ms R or IL: 1.15 R or IL: 0.96
MTIM(122) 5 --- 2.25 ms 1.88 ms 1.35 1.113
TCNT(123) 4 Constant for execution times 11.4 9.5 1.2 1.0
*DM for execution times
13.1 10.9
TSR(124) 4 When reading to a word 6.3 5.3
When reading to *DM
9.9 8.3
TSW(125) 4 When writing to a word 5.9 4.9
When writing to *DM
9.6 8.0
ANDW(130) 5 Constant AND word → word 6.8 5.6 1.35 1.13
*DM AND *DM → *DM
11.0 9.1
ORW(131) 5 Constant OR word → word 6.8 5.6
*DM OR *DM → *DM
11.1 9.3
*Note: CV500 = CV500 or CVM1-CPU01-EV2; CV1000 = CV1000, CV2000, or CVM1-CPU11/21-EV2
Instruction Execution Times Section 6-4
