Omron SYSMAC CV Series

Appendix AInstruction Set
519
Note Instructions marked with an asterisk (*) are supported by version-2 CVM1 CPUs only.
Bit Tests
Code Mnemonic Name
350 TST* BIT TEST
351 TSTN* BIT TEST
Symbol Math Instructions
Code Mnemonic Name
400
+(j)*
SIGNED BINARY ADD
WITHOUT CARRY
401
+L(j)*
DOUBLE SIGNED BINARY
ADD WITHOUT CARRY
402
+C(j)*
SIGNED BINARY ADD
WITH CARRY
403
+CL(j)*
DOUBLE SIGNED BINARY
ADD WITH CARRY
404
+B(j)*
BCD ADD WITHOUT
CARRY
405
+BL(j)*
DOUBLE BCD ADD
WITHOUT CARRY
406
+BC(j)*
BCD ADD WITH CARRY
407
+BCL(j)*
DOUBLE BCD ADD WITH
CARRY
410
–(j)*
SIGNED BINARY
SUBTRACT WITHOUT
CARRY
411
-L(j)*
DOUBLE SIGNED BINARY
SUBTRACT WITHOUT
CARRY
412
–C(j)*
SIGNED BINARY
SUBTRACT WITH CARRY
413
–CL(j)*
DOUBLE SIGNED BINARY
SUBTRACT WITH CARRY
414
–B(j)*
BCD SUBTRACT WITHOUT
CARRY
415
–BL(j)*
DOUBLE BCD SUBTRACT
WITHOUT CARRY
416
–BC(j)*
BCD SUBTRACT WITH
CARRY
417
–BCL(j)*
DOUBLE BCD SUBTRACT
WITH CARRY
420
*(j)*
SIGNED BINARY MULTIPLY
421
*L(j)*
DOUBLE SIGNED BINARY
MULTIPLY
422
*U(j)*
UNSIGNED BINARY
MULTIPLY
423
*UL(j)*
DOUBLE UNSIGNED
BINARY MULTIPLY
424
*B(j)*
BCD MULTIPLY
425
*BL(j)*
DOUBLE BCD MULTIPLY
430
/(j)*
SIGNED BINARY DIVIDE
431
/L(j)*
DOUBLE SIGNED BINARY
DIVIDE
432
/U(j)*
UNSIGNED BINARY DIVIDE
433
/UL(j)*
DOUBLE UNSIGNED
BINARY DIVIDE
434
/B(j)*
BCD DIVIDE
435
/BL(j)*
DOUBLE BCD DIVIDE
Floating-point Math Instructions
Code Mnemonic Name
450
FIX(j)*
FLOATING-TO-16-BIT
451
FIXL(j)*
FLOATING-TO-32-BIT
452
FLT(j)*
16-BIT-TO-FLOATING
453
FLTL(j)*
32-BIT-TO-FLOATING
454
+F(j)*
FLOATING-POINT ADD
455
–F(j)*
FLOATING-POINT
SUBTRACT
456
*F(j)*
FLOATING-POINT
MULTIPLY
457
/F(j)*
FLOATING-POINT DIVIDE
458
RAD(j)*
DEGREES-TO-RADIANS
459
DEG(j)*
RADIANS-TO-DEGREES
460
SIN(j)*
SINE
461
COS(j)*
COSINE
462
TAN(j)*
TANGENT
463
ASIN(j)*
SINE-TO-ANGLE
464
ACOS(j)*
COSINE-TO-ANGLE
465
ATAN(j)*
TANGENT-TO-ANGLE
466
SQRT(j)*
SQUARE ROOT
467
EXP(j)*
EXPONENT
468
LOG(j)*
LOGARITHM
