52
Word(s) FunctionBit(s)
08 to 15 Peripheral Connected Flags for RT #0 to RT #7 of
RM/2 #1
A308 00 to 07 Peripheral Connected Flags for RT #0 to RT #7 of
RM/2 #2
08 to 15 Peripheral Connected Flags for RT #0 to RT #7 of
RM/2 #3
A309 00 to 15 Peripheral Device Cycle Time (binary)
A310 to A325 00 to 15 CPU Bus Unit Service Interval (binary)
A326 to A342 00 to 15 Not used.
A343 00 to 02 Memory Card Type
03 to 06 Not used.
07 Memory Card Format Error Flag
08 Memory Card Transfer Error Flag
09 Memory Card Write Error Flag
10 Memory Card Read Error Flag
11 FIle Missing Flag
12 Memory Card Write Flag
13 Memory Card Instruction Flag
14 Accessing Memory Card Flag
15 Memory Card Protected Flag
A344 to 345 00 to 15 Not used.
A346 00 to 15 Number of Words Remaining to transfer to memory
card for a file read/write instruction (BCD)
A347 to A399 00 to 15 Not used.
A400 00 to 15 Error Code
A401 00 to 04 Not used.
06 FALS Error Flag
07 SFC Fatal Error Flag
08 Cycle Time Too Long Flag
09 Program Error Flag
10 I/O Setting Error Flag
11 Too Many I/O Points Flag
12 CPU Bus Error Flag
13 Duplication Error Flag
14 I/O Bus Error Flag
15 Memory Error Flag
A402 00 to 01 Not used.
02 Power Interruption Flag
03 CPU Bus Unit Setting Error Flag
04 Battery Low Flag
05 SYSMAC BUS Error Flag
06 SYSMAC BUS/2 Error Flag
07 CPU Bus Unit Error Flag
08 Not used.
09 I/O Verification Error Flag
10 Not used.
11 SFC Non-fatal Error Flag
12 Indirect DM Error Flag
13 Jump Error Flag
14 Not used.
15 FAL Error Flag
Auxiliary Area Section 3-6
