53
Word(s) FunctionBit(s)
A403 00 to 08 Memory Error Area Location
09 Memory Card Startup Transfer Error Flag
10 to 15 Not used.
A404 00 to 07 I/O Bus Error Slot Number (BCD)
08 to 15 I/O Bus Error Rack Number (BCD)
A405 00 to 15 CPU Bus Unit Error Unit Number
A406 00 to 15 Not used.
A407 00 to 15 Total I/O Words on CPU and Expansion Racks
(BCD)
A408 00 to 15 Total SYSMAC BUS/2 I/O Words (BCD)
A409 00 to 07 Duplicate Rack Number
08 to 14 Not used
15 Duplicate System Parameter Words Flag
A410 00 to 15 CPU Bus Unit Duplicate Number
A411 to A413 00 to 15 Not used.
A414 00 to 15 SFC Fatal Error Code
A415 to A417 00 to 15 Not used.
A418 00 to 15 SFC Non-fatal Error Code
A419 00 to 07 CPU-recognized Rack Numbers
08 to 15 Not used.
A420 to A421 00 to 15 Not used.
A422 00 to 15 CPU Bus Unit Error Unit Number
A423 00 to 13 Not used.
14 CPU Bus Unit Number Setting Error Flag
15 CPU Bus Link Error Flag
A424 00 to 03 SYSMAC BUS/2 Error Master Number
04 to 15 Not used.
A425 00 to 07 SYSMAC BUS Error Master Number
08 to 15 Not used.
A426 00 to 13 Not used
14 Memory Card Battery Low Flag
15 PC Battery Low Flag
A427 00 to 15 CPU Bus Unit Setting Error Unit Number
A428 to A429 00 to 15 Not used.
A430 to A461 00 to 15 Executed FAL Number
A462 to A463 00 to 15 Maximum Cycle Time (BCD, 8 digits)
A464 to A465 00 to 15 Present Cycle Time (BCD, 8 digits)
A466 to A469 00 to 15 Not used.
A470 to A477 00 to 15 SYSMAC BUS Error Codes:
RM # 0 (A470) RM #1 (A471)
RM # 2 (A472) RM #3 (A473)
RM # 4 (A474) RM #5 (A475)
RM # 6 (A476) RM #7 (A477)
A478 00 to 15 Total SYSMAC BUS I/O Words (BCD)
A479 00 to 15 Not used.
A480 to A499 00 to 15 SYSMAC BUS/2 Error Unit Number:
RM # 0 (A480 to A484) RM #1 (A485 to A489)
RM # 2 (A490 to A494) RM #3 (A495 to A499)
Auxiliary Area Section 3-6
