b. Disk backplane auxiliary signal (DBP SIG) cable
See Servicing the Disk Backplane.
c. Front LED indicator module (FIM) ribbon cable
See Servicing the Front LED Indicator Module.
Callout Description
1 Disk backplane power (DBP PWR) cable
2 Disk backplane auxiliary signal (DBP SIG) cable
3 Front LED indicator module (FIM) ribbon cable
5. Reinstall the following components:
Chapter 12
Install the Motherboard Assembly
12-14
