Note:
References to “left” or “right” in this procedure assume that you are facing the back
of the equipment rack.
1. To prevent the rack from tipping forward when the server is extended, ensure that the
rack anti-tilt bar is extended.
Caution:
To reduce the risk of personal injury, stabilize the rack cabinet and extend the
anti-tilt bar before extending the server from the rack.
For instructions to stabilize the rack, see Stabilize the Rack.
2. To make it easier to remove the CMA, extend the server approximately 13 cm (5 inches)
out of the front of the rack.
3. To remove the cables from the CMA:
a. Disconnect all cables from the back of the server.
b. If applicable, remove any additional Velcro straps that were installed to bundle the
cables.
c. Unwrap the six Velcro straps that are securing the cables.
d. Open the three cable covers to the fully opened position.
e. Remove the cables from the CMA and set them aside.
4. To disconnect connector D:
a. Press the green release tab (callout 1) on the slide-rail latching bracket toward the
left and slide the connector D out of the left slide-rail [1 and 2].
When you slide connector D out of the left slide-rail, the slide-rail latching bracket
portion of the connector remains in place. You disconnect connector D in the next
step.
Note:
After you disconnect connector D, do not allow the CMA to hang under its
own weight. Throughout the remainder of this procedure, the CMA must be
supported until all the remaining connectors are disconnected and the CMA
can be placed on a flat surface.
Appendix C
Rackmounting the Server
C-25
