3: Troubleshooting Automated Tests
32
The report shows the results of the most recent hourly test, the daily tests that have run since the last
weekly test, and the last 53 weekly tests. Test results are reported, as described in Ta bl e 7 on page 32.
Figure 23 Automated Test Summary Screen


     
     
     
     
     
     
     
     
     
     
     
     
     
     
     



Table 7 Automated Test Summary Results
Result RFU Indicator Definition Required Action
Pass
Hourglass
All tests passed None
Fail/D A non-critical failure has been
detected. Affected component
does not affect therapy delivery.
Turn the Therapy Knob to Monitor. A Technical Alarm
indicating the failed component is displayed. Troubleshoot
as described in “Troubleshooting Process” on page 43.
Fail/BW Blinking red X Battery low or malfunctioning. Charge the battery as soon as possible and/or replace the
battery with a charged battery.
Fail/CX
Solid red X,
chirp
An ECG cable failure has been
detected
Replace the ECG cable and run Op Check. Troubleshoot as
described in “Troubleshooting Process” on page 43 if
persists.
Fail/DX A critical device failure has been
detected.
Turn the Therapy Knob to Monitor. A Technical Alarm
indicates a problem has occurred. Troubleshoot as described
in “Troubleshooting Process” on page 43.
