3: Troubleshooting Operational Check
36
Charge Button: Test s t h e Charge button function.
If no cable is attached, the test is skipped.
If the Pads cable is attached, you are prompted to Verify Test Load is Attached and Press the
Charge Button. Follow the prompt.
If external paddles are attached, you are prompted to Verify Paddles are in Holders and Press the
Charge Button. Follow the prompt.
If the device does not detect a press of the Charge button within 10 seconds, the message If the
Charge button does not work, select Charge from the menu below is displayed. If the Charge
button is not working, press Charge from the No Button Response menu. The test is marked Fail,
and the Op Check fails.
Shock Button: Test s t h e Shock button (or the Shock buttons on the external paddles) function.
If a pads cable and test load are not attached, or if external paddles are not attached and in the paddle
holder, the test is skipped and marked Not Tested.
Once charged, the Shock button(s) flash(es) and you are prompted to Press Shock button
orPress
Shock buttons on paddles. Follow the prompt.
If the device does not detect a press of the Shock button within 10 seconds, the prompt If the Shock
button does not work, select Shock from the menu below is displayed. If the Shock button(s) is
(are) not working, press Shock from the No Button Response menu. The test is marked Fail, and
the Op Check fails.
NOTE: The device automatically disarms after the time specified in the configuration is reached. The message
Defib Disarmed is displayed in this case.
Audio Test: Plays a voice prompt and asks you to reply whether the prompt was heard.
If a shock was delivered during the Shock test, the prompt “Shock Delivered” is annunciated. If a
shock was not delivered, then the prompt “No Shock Delivered” is annunciated. When you hear the
prompt, use the navigation buttons to select Yes, then press the Menu Select button.
Sync Button: Follow the Press and Release Sync Button
prompt.
If the device does not detect a press of the Sync button within 10 seconds, the prompt If the Sync
button does not work, select Sync from the menu below is displayed. If the Sync button is not
working, press Sync from the No Button Response menu. The test is marked Fail, and the
Op Check fails.
TIP: Once you have responded to the Sync Button prompt, you can leave the HeartStart XL+ unattended,
and the Op Check will complete.
Therapy Delivery Test: If the Pacing option is installed, this test will test pacing as well. Depending on
your configuration and attached cables, the test may display:
• Pass/Pads
• Pass/External Paddles
• Fail/No Cable
• Fail/Pads
• Fail/External Paddles
• Fail/Internal Paddles
• Fail/Battery
• Fail
