Components Troubleshooting 3: Troubleshooting
55
In Table 18 “ECG Diagnostic with the Hardware Error Log”, the Numeric IDs of the (9:nn) format
indicate problems with Leads ECG, and the ones of the (10:nn) format indicate problems with Pads
ECG.
Table 18 ECG Diagnostic with the Hardware Error Log
Numeric ID Error Log Message Possible Cause Suggested Action
(9:1) (10:1) RFU Test Timed Out ECG test is not completed in time Run Op Check
(9:2) (10:2) Comm Failure: nn
Communication failure
Replace Processor PCA
(9:3) (10:3) DSP File CRC Check Failure - xxx • Reinstall software
• Replace Processor PCA
(9:4) (10:4) Communications Failure: Test Timeout
(9:5) (10:5) DSP POST missing at start of test Self-test result is not received
(9:6-8, 20)
(10:6-8)
Bad number of channels from DSP: xxx Leads / Pads calibration failure
(9:9) (10:9) DSP POST failure, test data unavailable
Leads / Pads test failure
(9:10), (10:10) Bad IDS revision from DSP. xxx
(9:11) ECG Leads Calibration Fail ECG Leads gain failure
Replace Processor PCA
(9:12) ECG Leads PLL Time Fail ECG Leads clock failure
(9:13) ECG Leads Reference Error ECG Leads reference error
(9:14) ECG Failure - Lead: n, Type: Gain, xxx
ECG Leads failure
(9:15) ECG Failure - Lead: n, Type: Noise, xxx
(9:16) ECG Failure - Lead: n, Type: Bias xxx ECG Leads failure • Replace leads cable
•Replace Therapy Port
• Replace Processor PCA
(9:21) Leads Off ECG Common Leakage
Current: nn
Op Check performed without
ECG cable
Run Op Check with
ECG cable
(9:22) ECG Failure - Lead: <reason>
ECG Common Leakage Current: nn
(9:23) ECG Failure - Lead: <reason>
(9:24) ECG Leads Test Rerun Skipped by User
(10:11) ECG Pads Calibration Fail ECG Pads gain failure
Replace Therapy PCA
(10:12) ECG Pads PLL Time Fail ECG Pads clock failure
(10:13) ECG Pads Reference Error ECG Pads reference error
(10:14) ECG Failure - Pad: n, Type: Gain, xxx
ECG Pads failure
(10:15) ECG Failure - Pad: n, Type: Noise, xxx
(10:16) ECG Failure - Pad: n, Type: Bias xxx ECG Pads failure • Replace Therapy cable
•Replace Therapy Port
• Replace Therapy PCA
(10:20) Pads Common Mode Impedance:
Processor PCA failure Replace Processor PCA
(10:21) Pads PCI Impedance Failure: xx
(10:22) Cannot run ECG tests with internal
paddles
ECG test failure
Run Op Check
(10:23-26) Pads/Paddles Current Source... Replace Therapy PCA
