6 Carefully lift the Rear Case cover no more than 2 inches (5 cm).
7 Put your right hand fingers through the AC mains and LAN openings and hold the Rear Case cover
while pressing the latch behind the paddle connector with your left hand to separate, see Figure 49.
CAUTION: Be careful not to bend or damage the pins in front of the paddle connector.
8 Lift the Rear Case straight up.
Figure 48 Case Screws
Figure 49 Separating the Case
