Startup and validation
108580_en_02 PHOENIX CONTACT 107 / 272
Click on the desired programming language (in the example: “Add LD Code Work-
sheet”).
You can now define variables, for example (see “Creating variables” on page 108).
Creating a new POU To create a new POU, proceed as follows:
Click on “Programming (x)” in the “COMPONENTS” area.
Click on the arrow next to “Local (x)”.
Right-click on “Programs (x)”.
In the context menu, select “Add Program”.
Figure 4-24 “Add Program” context menu
If you have created a new POU, you will be prompted to select the programming language
when you open the worksheet for the first time (see Figure 4-23).
Once you have selected the programming language, the POU editor group opens.
