RFC 4072S
186 / 272
PHOENIX CONTACT 108580_en_02
F_ADDR_XXXXX_IPAR_EN *) BOOL Initiate application of the iParameters
This variable is set in the application in order to initiate the application
of the iParameters.
Intentionally setting of the F_ADDR_XXXXX_IPAR_EN variable starts
the process for applying the iParameters. The process depends on
the F-Device used. For more detailed information, please refer to the
device-specific user documentation.
F_ADDR_XXXXX_CHF_ACK_REQ *) BOOL A channel error in the F-Device can be acknowledged
(CHF_ACK_REQ_S).
(Only for F-Devices in accordance with PROFIsafe profile V2.6.1.)
F_ADDR_XXXXX_CHF_ACK_REI *) BOOL Channel error acknowledgement (CHF_ACK_C)
(Only for F-Devices in accordance with PROFIsafe profile V2.6.1.)
F_ADDR_XXXXX_CE_CRC_H *) BOOL Communication error (F_CE_CRC_H)
Local F-Host driver reports communication error.
F_ADDR_XXXXX_WD_TIMEOUT_H *) BOOL Communication error (F_WD_TIMEOUT_H)
Local F-Host driver reports communication error.
F_ADDR_XXXXX_LOOPBACK *) BOOL Communication error (loopback check)
Local F-Host driver reports communication error.
*) XXXXX = Number of the F-Device (e.g., F_ADDR_00001_PASS_ON, see Figure 4-65 on page 140)
Table 8-6 Management/diagnostic variables for each configured F-Device
System variable Ty pe Meaning
WARNING:
Depending on the application, applying the iParameters
can result in hazardous states
Take appropriate measures to ensure that your sys-
tem/machine does not present any danger when the appli-
cation of the iParameters is initiated and/or iParameters
are applied.
WARNING:
The variables specified in the table can be toggled. Program an evaluation function in the
PLCnext Engineer software (e.g., using edge detection).
